24V DC UPS designed specifically for industrial automation and controls. This 325W UPS comes with hardwire input/output and can be mounted on a DIN Rail or any control panel. It features temperature-compensated battery charging that helps prolong the battery life. It comes with a 2-year standard warranty.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Communications & Management Attributes
• Alarm : alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
• Complementary Attributes
• Curve Load Maximum : 100 %
• Curve X Axis Maximum : 100 %
• Curve X Axis Minimum : 0 %
• Curve Y Axis Maximum : 100 %
• Curve Y Axis Minimum : 50 %
• Maximum Configurable Power In VA : 500 VA
• Important Information Attributes
• Persona Type Ids : EUA, VR
• Persona Type Names : Consumer, IT Channel Partner
• Efficiency At Full Load : 75...154 V adjustable, 82...144 V, 94 % full load)
• Provided Equipment : CD with software, Documentation CD, Installation guide, Smart UPS signalling RS-232 cable
• Output Frequency Sync To Mains : 47...53 Hz for 50 Hz nominal sync to mains, 57...63 Hz for 60 Hz nominal sync to mains
• Carbon Footprint Of The Distribution Phase A4 : 4.5705466485, 5 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4 : 7 kg CO2 eq., 6.9692668576
• Carbon Footprint Of The Installation Phase A5 : 1.3286913582, 1 kg CO2 eq.
• Carbon Footprint Of The Manufacturing Phase A1 To A3 : 191 kg CO2 eq., 191.3224100291
• Carbon Footprint Of The Use Phase B2 B3 B4 B6 : 295 kg CO2 eq., 294.6147179487
• Local Data Status : Publishable
• Local Publishable Date : 2026-01-09
• HTML Description : APC DIN Rail - Panel Mount UPS with Standard Battery 500VA 120VAPC Industrial,325 Watts /500 VA,Input 120V /Output 120V, Interface Port DB-9 RS-232, SmartSlotIncludes: CD with software, Documentation CD, Installation guide, Smart UPS signalling RS-232 cable
• Manufacturer : American Power Conversion Corp. (APC)
• Device Type : UPS - Network and Server
• Serviceability : No
• Traceability : Yes
• Field Service Division : SPIBS
• Legacy WEEE Scope : In
• Scope Perimeter : At least in Europe
• EOLI Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1612028_EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• ROHS EUR In Scope : Yes
• ROHS EUR Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
• Green Premium Status For Reporting : Green Premium product
• With Recycled Cardboard : No
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• WD Status : L - LOB initialized
• Dangerous Goods Code : BATTERIES WET NON SPILLABLE (ELECTRIC STORAGE or LEAD ACID)
• Function Option Id : STANDARD
• Function Option : Standard
• Market Segmentation Id : RESIDENTIAL
• Market Segmentation : Residential
• Curve Equation : efficiency
• Curve Load Maximum : 100 %
• Curve X Axis Maximum : 100 %
• Curve X Axis Minimum : 0 %
• Curve X Axis Title : load
• Curve X Axis Units : percentage
• Curve Y Axis Maximum : 100 %
• Curve Y Axis Minimum : 50 %
• Curve Y Axis Title : efficiency
• Curve Y Axis Units : percentage
• Energy Efficiency Optimized : False
• Filtering : Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m
• Maximum Configurable Power In VA : 500 VA
• Mounting Preference : no preference
• Number Of Input Connectors : 1 Hard Wire 3-wire (1PH+N+G)
• Number Of Tare Power : 15 W
• Output Connector Type : Hard Wire 3-wire (H N + E) for 1 zone(s)
• Package Weight Lbs : 13.32 kg
• Product Availability : Stock - Normally stocked in distribution facility
• Product Or Component Type : uninterruptible power supply (UPS)
• Redundant : No
• Returnability : Yes
• Show Note Op Temperature : No
• Surge Energy Rating : 540 J
• Sustainable Packaging : No
• Total Lifecycle Carbon Footprint : 499 kg CO2 eq.
• Typical Recharge Time : 2 h
• Ups Size : WS
• Usb Compatible : No
• Waveform Type : Sine wave
• Emergency Power Off EPO : Yes
• Max Configurable Power Watts : 325 W
• Relationship Type : Compatible relationship
• Pep Code : ENVPEP1612028EN
• Pep Verification Date : 2025-10-25
• PCR Version : PEP-PCR-ed4-2021 09 06
• PSR Version : PSR-0010-ed1.1-EN-2015 10 16
• Type Of Verification For The Pep : Independent internal review
• Functional Unit Description : The functional unit is the transmission of electricity between electrical/electronic equipment and a power source for a distance of 2.5m for up to 10A of current at 230V AC
• Functional Unit Unit : unit
• Product Kit Identifier : N
• Product Manager : BALASUBRAMANI HARI
• Environment Attributes Main
• EU ROHS Directive : Compliant By Exemption​, Compliant with Exemptions
• ROHS Exemption Information : Yes
• Take Back : Yes
• Recycled Metal Content At Cr Level : 0 %
• Mercury Free : Yes
• Carbon Footprint : 498.8056328421
• Circularity Profile : ENVEOLI1612028_EN
• Environmental Disclosure : ENVPEP1612028EN
• IP Degree Of Protection : IP20
• Online Thermal Dissipation : 90 Btu/h
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : No
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Relative Humidity : 0-95 %
• Storage Altitude : 0-50000 ft
• Storage Relative Humidity : 0-95 %
• Pep Code : ENVPEP1612028EN
• Pep Verification Date : 2025-10-25
• PCR Version : PEP-PCR-ed4-2021 09 06
• PSR Version : PSR-0010-ed1.1-EN-2015 10 16
• Type Of Verification For The Pep : Independent internal review
• General Attributes
• Provided Equipment : CD with software, Documentation CD, Installation guide, Smart UPS signalling RS-232 cable
• Product Or Component Type : uninterruptible power supply (UPS)
• Output Attributes
• Harmonic Distortion : Less than 5%
• Output Voltage : 120 V
• Surge Protection And Filtering Attributes
• Filtering : Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : m
• Surge Energy Rating : 540 J
• Contractual Warranty Attributes
• Warranty Period : 2 years repair or replace
• Warranty : 2 years repair or replace
• Input Attributes
• Efficiency At Full Load : 75...154 V adjustable, 82...144 V, 94 % full load)
• Input Frequency : 50/60 Hz +/- 3 Hz auto-sensing
• Main Input Voltage : 120 V
• Batteries & Runtime Attributes
• Removable Battery : USER_REPLACEABLE
• Battery Curve : B
• Battery Power In VAH : 120 VAh runtime
• Battery Slots Empty : 1
• Included Battery Modules : 1
• Battery Charge Power Watts : 60 W rated
• Replacement Battery : APCRBC135
