3M

3M™ ScotchCode™ Wire Marker Tape Refill Roll SDR-4, 50 Rolls/Case

MARKER - WIRE TAPE

MMMSDR4 SDR-4 54007093732
5.91 / Roll
http://schema.org/OutOfStock
Mayer-DDS-3M™ ScotchCode™ Wire Marker Tape Refill Roll SDR-4, 50 Rolls/Case-1
  • Applications: Marking Wire And Cable
  • Country of Origin: USA
  • Material: Plastic
  • Max. Operating Temperature: 121.0 °C, 250.0 °F
  • Overall Length: 2.4 m
  • Product Type: Identification
  • Width: 5.46 mm
3M™ ScotchCode™ Wire Marker Tape Refill Roll SDR is available in ten NEMA colors, individual numbers and consecutive numbers, letters and symbols.
QTY
  • Product Description
  • Features
  • Specifications
3M™ ScotchCode™ Wire Marker Tape Refill Roll SDR is available in ten NEMA colors, individual numbers and consecutive numbers, letters and symbols.
  • Features
    • High tack, acrylic adhesive that resists solvents, oil and water and adheres firmly to insulation surfaces
    • Available in ten NEMA colors, individual numbers and consecutive numbers, letters and symbols
    • Can be used for applications with operating temperatures between -40°F (-40°C) to 250°F (121°C)
  • Specifications
    • Country of Origin : United States
    • Legend : 4
    • ETIM Class 7.0 : EC001530
    • ETIM Class 8.0 : EC001530
    • Legend Color : Black
    • Maximum Operating Temperature (Celsius) : 121.0 Degree
    • Maximum Operating Temperature (Fahrenheit) : 250.0 Degree
    • Application : Marking Wire and Cable
    • Dispenser/Marker Type : Tape Roll Refill
    • Manufacturing Origin : USA
    • Marker ID Style : Pre-printed
    • Marker Type : Dispenser
    • Material : Plastic
    • Maximum Insulation Outer Diameter (Metric) : 3.7 mm
    • Maximum Insulation Outside Diameter : 0.145 in
    • Maximum Recommended Voltage Rating : 600.0 V
    • Overall Length (Metric) : 2.4 m
    • Overall Width (Metric) : 5.46 mm
    • Printed Text Type : Number - 4
    • Product Type : Identification
    • Refill : Tape Roll
    • RoHS EU Comments : RoHS 2011/65/EU compliant without exemption
    • Solution for : Access Network: FTTH/FTTB/CATV
    • Tape Color : White
    • UV Resistant : No
    • Units per Case : 50.0
    • Voltage Application : Low Voltage
    • Wire Marker Products : Wire Marker Tape Dispenser and Refill Rolls
