Control relay, TeSys SK, 2NO, <= 690V, 120 V AC coil

Control relay, TeSys SK, 2NO, <= 690V, 120 V AC coil

SQDCA2SK20G7 CA2SK20G7 3389110564174
50.79 / EA
http://schema.org/OutOfStock
Mayer-DDS-Control relay, TeSys SK, 2NO, <= 690V, 120 V AC coil-1
  • Certifications: CB Scheme, CE, CULus, EAC, UKCA
  • Contact Configuration: 2 NO
  • Depth: 55.5 mm
  • Height: 56 mm
  • Net Weight: 0.132 kg
  • Standard: CSA C22.2 No 60947-5-1, EN/IEC 60947-5-1, UL 60947-5-1
  • Storage Temperature: -50-70 °C
  • Warranty Length: 18 mth
  • Width: 27 mm
QTY
  • Specifications
  • Environment
    • Product Certifications : CB Scheme || cULus || EAC || CE || UKCA
    • Ambient Air Temperature For Operation : -20-50 °C
    • Standards : EN/IEC 60947-5-1 || UL 60947-5-1 || CSA C22.2 No 60947-5-1
    • Ambient Air Temperature For Storage : -50-70 °C
    • Protective Treatment : TC IEC 60068
    • Ip Degree Of Protection : IP2X
    • Operating Altitude : 6561.68 ft (2000 m) without derating
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1503003EN
    • Sustainable Offer Status : Green Premium product
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Circularity Profile : ENVEOLI1503003EN
    • Eu Rohs Directive : Compliant with Exemptions
  • Complementary
    • Height : 56 mm
    • Control Circuit Voltage Limits : drop-out: 0.2...0.75 Uc (at <50 °C) || operational: 0.85...1.1 Uc (at <50 °C)
    • [Ith] Conventional Free Air Thermal Current : 10 A (at 55 °C)
    • Mounting Support : rail || plate
    • Associated Fuse Rating : 10 A gL conforming to VDE 0660 || 10 A gL conforming to IEC 60947
    • Net Weight : 0.132 kg
    • Inrush Power In Va : 16-16 VA (at 20 °C)
    • Connections - Terminals : screw clamp terminals 1 1.5-6 mm²solid || screw clamp terminals 2 1.5-4 mm²solid || screw clamp terminals 1 0.5-6 mm²flexible without cable end || screw clamp terminals 1 0.35-6 mm²flexible with cable end || screw clamp terminals 2 0.35-1.5 mm²flexible with cable end || screw clamp terminals 2 0.35-2.5 mm²flexible without cable end
    • Maximum Operating Rate : 1200 cyc/h
    • Tightening Torque : 0.8 N.m screw clamp terminals pozidriv No 1
    • Mechanical Durability : 10 Mcycles
    • Hold-In Power Consumption In Va : 4.2-4.2 VA (at 20 °C)
    • Operating Time : 6...8 ms coil de-energisation and NO opening || 7...14 ms coil energisation and NO closing || 8...10 ms coil de-energisation and NC closing || 8...16 ms coil energisation and NC opening
    • Width : 27 mm
    • Depth : 55.5 mm
    • [Ui] Rated Insulation Voltage : 690 V IEC 60947 || 690 V VDE 0110 group C || 690 V BS 5424 || 690 V UL 508 || 690 V CSA C22.2 No 14
    • Heat Dissipation : 1.4-1.4 W
  • Specifications
    • [Ue] Rated Operational Voltage : <= 690 V <= 400 Hz
    • Control Circuit Type : AC 50/60 Hz
    • [Uc] Control Circuit Voltage : 120 V AC 50/60 Hz
    • Contactor Application : control circuit
    • Product Or Component Type : control relay
    • Product Name : TeSys CASK
    • Range : TeSys
    • Pole Contact Composition : 2 NO
    • Utilisation Category : DC-13 || AC-15
    • Device Short Name : CA2SK
