SQUARE D

plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO

PLUG-IN ELECTROMECHANICAL RELA

SQDABR7S11 ABR7S11 3389110251470
22.11 / EA
http://schema.org/OutOfStock
plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO
  • Dielectric Strength: 4000 V
  • Warranty Length: 18 mth
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for pre-wired system. This is an electromechanical plug-in relays for 24VDC prewired sub-bases. It has 1 NO contact. Its mechanical durability is up to 20000000 cycles. It immunity to microbreaks is up to 1ms. It is used to to control the power along with switching the smaller current values in a control circuit. It is 5mm wide. It weighs 0.005kg. It is suitable into any types of industrial applications needing rapid connection of I/O modules (digital, analog, and counter) to operative parts. It is suitable for use with ABE7R16T111, ABE7R16M111, ABE7P16M111, and ABE7P16T111 sub-bases. It is delivered in 1 package (PCE type) containing 4 units. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment.
QTY
  • Product Description
  • Features
  • Specifications
This product is part of the Modicon ABE7 range, an offer of connection sub-bases for pre-wired system. This is an electromechanical plug-in relays for 24VDC prewired sub-bases. It has 1 NO contact. Its mechanical durability is up to 20000000 cycles. It immunity to microbreaks is up to 1ms. It is used to to control the power along with switching the smaller current values in a control circuit. It is 5mm wide. It weighs 0.005kg. It is suitable into any types of industrial applications needing rapid connection of I/O modules (digital, analog, and counter) to operative parts. It is suitable for use with ABE7R16T111, ABE7R16M111, ABE7P16M111, and ABE7P16T111 sub-bases. It is delivered in 1 package (PCE type) containing 4 units. Modicon ABE7 means greater simplicity to rationalise wiring in automation system equipment.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Complementary Attributes
    • Maximum Switching Voltage : 250 V AC 50/60 Hz IEC 60947-5-1, 30 V DC IEC 60947-5-1
    • Control Circuit Type : DC
    • Maximum Power Dissipation Per Pole : 0.17 W
    • Minimum Switching Current : 100 mA >= 5 V
    • Uc Control Circuit Voltage : 24 V
    • Uimp Rated Impulse Withstand Voltage : 6 kV IEC 60947-1
  • Important Information Attributes
    • Persona Type Ids : EU, OM, OM8
    • Persona Type Names : End User, Original Equipment Manufacturer, OEM - Control Panelbuilder
    • Electrical Durability : 500000 cycles 2000 mA 230 V AC-12, 500000 cycles 3000 mA 24 V DC-12, 500000 cycles 400 mA 230 V AC-15, 500000 cycles 500 mA 24 V DC-13 10 ms
    • Operating Rate In Hz : 20 Hz no load, 0.1 Hz at Ie
    • Medium Desc : plug-in electromechanical relay - 5 mm - 24 V DC - 1 NO
    • Local Data Status : Publishable
    • Local Publishable Date : 2026-01-12
    • Global Commercial Status : Commercialised
    • Return Indicator : N
    • Stocking Flag : Y
    • Legacy Weee Scope : In
    • Scope Perimeter : At least in Europe
    • Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
    • Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
    • Rohs Eur In Scope : No
    • Rohs Eur Status : Compliant
    • Rohs Eur Full Compliance Status : Compliant
    • China Rohs In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : INDUSTRIAL
    • Market Segmentation : Industrial
    • Product Kit Identifier : N
    • Associated Fuse Rating : 1 A, fast blow
    • Contacts Type And Composition : 1 NO
    • Dielectric Strength : 4000 V IEC 60947-1
    • Drop Out Current : 0.5 mA 20 °C
    • Drop Out Voltage : 2 V 20 °C
    • Max Immunity To Microbreaks : 1 ms
    • Mechanical Durability : 20000000 cycles
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : plug-in electromechanical relay
    • Quantity Per Set : set of 4
    • Range Of Product : Advantys Telefast ABE7
    • Returnability : No
    • Sustainable Packaging : No
    • Threshold Tripping Voltage : 16.8 V 40 °C
    • Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Width Pitch Dimension : 5 mm
    • Ith Conventional Free Air Thermal Current : 6 A
  • Environment Attributes Main
    • Product Compatibility : ABE7R16T111, ABE7R16M111, ABE7P16M111, ABE7P16T111
    • Take Back : Nej
    • Reach Free Shvc : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • China Rohs Regulation : X
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Eu Rohs Directive : Compliant
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Reach Free Of Svhc : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
  • General Attributes
    • Product Or Component Type : plug-in electromechanical relay
    • Range Of Product : Advantys Telefast ABE7
  • ETIM
    • ETIM 8 : EC001652
    • ETIM 9 : EC001652
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : Latvia, United States
