This discrete input module is part of the Modicon X80 range, an offer of common input/output and communication modules, power supplies and racks for Modicon M340 and Modicon M580. This product is composed of 16 input channels and it is supplied with 200 to 240V AC. This ruggedized product can be used in more severe environments, and operate in an extended temperature range, from -25°C to +70°C/-13°F to 158°F. Modicon X80 modules provide a single environment for the deployment of I/O modules in automation architectures by reducing spare parts inventory, maintenance and training costs. This product is IP20 rated and offers 565019 hours of MTBF. This discrete module has a weight of 0.156kg and dimensions of 32x131x86mm. This product meets the needs of our customers from Smart Infrastructure, Water and Waste Water, Consumer Packaged Goods, Mining Minerals Metals, Data centers and Power generation. This product is certified by CE, UL, CSA, RCM, EAC, UKCA, Merchant Navy and meets EN 61000-6-5, EN 61850-3, EN 61131-2 type 1 standards. This module is compatible with Modicon M340, M580 (Local or Remote I/O) PLCs with a 40-way caged or spring-type removable terminal block. The product must be installed on the rack and fixed with 2 screws.

• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov

• Complementary
• Mtbf Reliability : 3700000 H
• Network Frequency : 50/60 Hz
• Voltage Range : 170...264 V
• Ac Activation Filtering Time : 10 ms
• Status Led : 1 LED (Green) module operating (RUN) || 1 LED per channel (Green) channel diagnostic || 1 LED (Red) module error (ERR) || 1 LED (Red) module I/O
• Voltage Detection Threshold : < 80 V AC sensor fault || > 170 V AC sensor OK
• Insulation Resistance : > 10 MOhm 500 V DC
• Network Frequency Limits : 47-63 Hz
• Current State 1 Guaranteed : >= 3 mA
• Protection Type : 1 external fuse per group of channel 0.25 A fast blow
• Power Dissipation In W : 5 W
• Net Weight : 0.157 kg
• Input Compatibility : 2-wire proximity sensor IEC 60947-5-2 || 2-wire proximity sensor IEC 61131-2 Type 1
• Ac Deactivation Filtering Time : 20 ms
• Typical Current Consumption : 76 mA 3.3 V DC
• Current State 0 Guaranteed : <= 2 mA
• Input Impedance : 28000 Ohm
• Environmental data
• Rohs Exemption Information : Yes
• Packaging Made With Recycled Cardboard : Yes
• Mercury Free : Yes
• Environmental Disclosure : ENVPEP2402023EN
• Packaging Without Single Use Plastic : Yes
• Scip Number : 43b0fbab-d94b-43e8-be0a-0b39cadd288b
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Circularity Profile : ENVEOLI2402023EN
• Take-Back : No
• Carbon Footprint Of The Use Phase [B2, B3, B4, B6] : 10.588999999999999
• Carbon Footprint Of The Manufacturing Phase [A1 To A3] : 17.91578333333333
• Carbon Footprint Of The Distribution Phase [A4] : 0 kg CO2 eq.
• Carbon Footprint Of The Installation Phase [A5] : 0.3 kg CO2 eq.
• Sustainable Packaging : Yes
• Total Lifecycle Carbon Footprint : 29 kg CO2 eq.
• Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
• Carbon Footprint Of The End-Of-Life Phase [C1 To C4] : 0.37204176666666666
• Carbon Footprint (Kg Co2 Eq, Total Life Cycle) : 29.187865499999994
• Environment
• Ambient Air Temperature For Operation : -25-70 °C
• Shock Resistance : 30 gn
• Environmental Characteristic : gas resistant class Gx || gas resistant class 3C4 || dust resistant class 3S4 || sand resistant class 3S4 || salt resistant level 2 || mold growth resistant class 3B2 || fungal spore resistant class 3B2
• Dielectric Strength : 1780 V AC 50/60 Hz 1 min
• Vibration Resistance : 3 gn
• Ambient Air Temperature For Storage : -40-85 °C
• Relative Humidity : 0-95 % -25-70 °C without condensation
• Operating Altitude : 0...6561.68 ft (0...2000 m) || 2000...5000 m with derating factor
• Protective Treatment : conformal coating
• Ip Degree Of Protection : IP20
• Specifications
• Country of Origin : France
• Weight : 0.157 kg
• Range Of Product : Modicon X80
• Discrete Input Voltage : 200...240 V AC
• Product Or Component Type : discrete input module
• Input Type : capacitive
• Discrete Input Type : isolated
• Discrete Input Number : 16
• Product Specific Application : for severe environments
• Discrete Input Current : 3 mA
