discrete input module Modicon Momentum - 32 Input 24 V DC

32 DI 24VDC

SQD170ADI35000 170ADI35000 3595861000254
550.53 / EA
http://schema.org/OutOfStock
Mayer-DDS-discrete input module Modicon Momentum - 32 Input 24 V DC-1
  • Depth: 47.5 mm
  • Warranty Length: 18 mth
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic. It is a module with discrete input voltage of 24V DC. There is an isolation between channels and ground at 500V AC. It features 32 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.2kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
QTY
  • Product Description
  • Features
  • Specifications
This input base is part of the Modicon Momentum range, an offer of controller and IP20 monoblock I/Os for distributed control architecture. This discrete input base DC module offers 2 groups of 16 inputs, conforming to IEC 1131-2 type 1 with positive discrete input logic. It is a module with discrete input voltage of 24V DC. There is an isolation between channels and ground at 500V AC. It features 32 LEDs for channel status signaling. Its dimensions are 125mm (width) x 47.5mm (depth) x 141.5mm (height). It weighs 0.2kg. The main application of this module is infrastructures and energy, material handling, simple machine control. This product is certified by CE, CSA and UL. It is suitable for wall mount. Momentum is a flexible, modular family of components that easily snaps together and can be configured for a wide range of distributed I/O and control applications. System with 4 fundamental components that easily snap together in various combinations to form versatile control systems or sub-systems.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Assets
    • Cad : https://download.schneider-electric.com/files?p_Doc_Ref=ADI3400R&p_File_name=ADI3400R.dwg, https://download.schneider-electric.com/files?p_Doc_Ref=ADI3400R&p_File_name=ADI3400R.dxf, https://download.schneider-electric.com/files?p_Doc_Ref=ADI3500W&p_File_name=ADI3500W.dwg, https://download.schneider-electric.com/files?p_Doc_Ref=ADI3500W&p_File_name=ADI3500W.dxf
  • Conformance Attributes
    • Product Certifications : UL, CSA
  • Important Information Attributes
    • Persona Type Ids : EU, OM8, SI
    • Persona Type Names : End User, OEM - Control Panelbuilder, System Integrator
    • Terminals Description Plc N 1 : (5)IN_DIS 5, (L+)PW_POS, (12)IN_DIS 12, (9)IN_DIS 9, (14)IN_DIS 14, (7)IN_DIS 7, (4)IN_DIS 4, (6)IN_DIS 6, (10)IN_DIS 10, (2)IN_DIS 2, (8)IN_DIS 8, (M-)PW_NEG, (16)IN_DIS 16, (13)IN_DIS 13, (15)IN_DIS 15, (11)IN_DIS 11, (1)IN_DIS 1, (3)IN_DIS 3, (5)IN_DIS 5, (L+)PW_POS, (12)IN_DIS 12, (9)IN_DIS 9, (14)IN_DIS 14, (7)IN_DIS 7, (4)IN_DIS 4, (6)IN_DIS 6, (10)IN_DIS 10, (2)IN_DIS 2, (8)IN_DIS 8, (M-)PW_NEG, (16)IN_DIS 16, (13)IN_DIS 13, (15)IN_DIS 15, (11)IN_DIS 11, (1)IN_DIS 1, (3)IN_DIS 3, TB
    • Terminals Description Plc N 2 : (13)IN_DIS 29, (4)IN_DIS 20, (1L+)PW_POS, (11)IN_DIS 27, (8)IN_DIS 24, (6)IN_DIS 22, (16)IN_DIS 32, (1)IN_DIS 17, (2)IN_DIS 18, (2L+)PW_POS, (10)IN_DIS 26, (5)IN_DIS 21, (9)IN_DIS 25, (3)IN_DIS 19, (12)IN_DIS 28, (14)IN_DIS 30, (7)IN_DIS 23, (15)IN_DIS 31, TB_1, (13)IN_DIS 29, (4)IN_DIS 20, (1L+)PW_POS, (11)IN_DIS 27, (8)IN_DIS 24, (6)IN_DIS 22, (16)IN_DIS 32, (1)IN_DIS 17, (2)IN_DIS 18, (2L+)PW_POS, (10)IN_DIS 26, (5)IN_DIS 21, (9)IN_DIS 25, (3)IN_DIS 19, (12)IN_DIS 28, (14)IN_DIS 30, (7)IN_DIS 23, (15)IN_DIS 31
    • Medium Desc : discrete input module Modicon Momentum - 32 Input 24 V DC
    • Local Data Status : Publishable
    • Local Publishable Date : 2026-01-12
    • Global Commercial Status : Commercialised
    • Return Indicator : Y
    • Stocking Flag : N
    • Device Type : PLC System - PLC Component
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : IDIBS
    • Average Life Duration : 15 year(s)
    • Legacy Weee Scope : Out
    • Scope Perimeter : At least in Europe
    • Eoli Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI1403005EN
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • Rohs Eur In Scope : No
    • Rohs Eur Status : Compliant By Exemption
    • Rohs Eur Full Compliance Status : Compliant By Exemption
    • China Rohs In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Function Option Id : ADVANCED
    • Function Option : Advanced
    • Market Segmentation Id : INDUSTRIAL
    • Market Segmentation : Industrial
    • Product Kit Identifier : N
    • Current State 1 Guaranteed : >= 2.5 mA
    • Group Of Channels : 2 groups of 16 inputs
    • Isolation Between Channels And Bus : 500 V AC
    • Local Signalling : 32 LEDs for channel status
    • Marking : CE
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : discrete inputs base DC
    • Protective Treatment : TC
    • Range Of Product : Modicon Momentum automation platform
    • Returnability : Yes
    • Sustainable Packaging : No
    • Voltage Range : - 3...30 V
    • Dc Supply Voltage : 24-24 V
    • Time Delay At Signal Change : 3.3-3.3 ms
    • Pep Code : ENVPEP1403005EN
    • Height Nominal : 141.5 mm
    • Width Nominal : 125 mm
  • Environment Attributes Main
    • Take Back : Nej
    • Recycled Metal Content At Cr Level : 0 %
    • China Rohs Regulation : X
    • Mercury Free : Yes
    • Circularity Profile : ENVEOLI1403005EN
    • Environmental Disclosure : ENVPEP1403005EN
    • Eu Rohs Directive : Compliant By Exemption
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP1403005EN
  • General Attributes
    • Product Or Component Type : discrete inputs base DC
    • Range Of Product : Modicon Momentum automation platform
  • ETIM
    • ETIM 8 : EC001599
    • ETIM 9 : EC001599
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Input Attributes
    • Discrete Input Logic : positive
    • Discrete Input Number : 32
    • Input Voltage Limits : 24 V
  • Specifications
    • Depth : 47.5 mm
