Discrete input module, Modicon TM5, digital 4I, 100 to 240 V AC, 2 wires

MOD. 4DI 100-240VAC 2 WIRES BL

SQDTM5SDI4A TM5SDI4A 3595864074474
423.91 / EA
http://schema.org/OutOfStock
Mayer-DDS-Discrete input module, Modicon TM5, digital 4I, 100 to 240 V AC, 2 wires-1
  • Certifications: CSA, C-tick, CULus, GOST-R
  • Current: 34 mA, 5 V
  • Net Weight: 0.025 kg
  • Standard: CSA C22.2 No 142, CSA C22.2 No 213, IEC 61131-2, UL 508
  • Storage Temperature: -40-70 °C
  • Warranty Length: 18 mth
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. The digital output module provides 4 multi-voltage inputs 100/240 V AC. It provides a discrete input voltage of 100 to 240V AC, an input current consumption of 34mA at 5V DC bus. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an isolation between channel and bus at 2500V AC for 1min. It is furnished with 3 wires for electrical connection. It is an IP20 rated product. Its housing colour is black.It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
QTY
  • Product Description
  • Specifications
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. The digital output module provides 4 multi-voltage inputs 100/240 V AC. It provides a discrete input voltage of 100 to 240V AC, an input current consumption of 34mA at 5V DC bus. This product is part of a flexible and scalable I/O configuration for automation solutions. There is an isolation between channel and bus at 2500V AC for 1min. It is furnished with 3 wires for electrical connection. It is an IP20 rated product. Its housing colour is black.It weighs 0.025kg. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. This product is compatible with Modicon LMC058 motion controller and Modicon M258 logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
  • Environment
    • Product Certifications : cULus || CSA || GOST-R || C-tick
    • Standards : UL 508 || CSA C22.2 No 142 || IEC 61131-2 || CSA C22.2 No 213
    • Storage Altitude : 0-3000 m
    • Electromagnetic Compatibility : electrostatic discharge immunity test, 4 kV on contact IEC 61000-4-2 || electrostatic discharge immunity test, 8 kV in air IEC 61000-4-2 || susceptibility to electromagnetic fields, 1 V/m 2...2.7 GHz IEC 61000-4-3 || susceptibility to electromagnetic fields, 10 V/m 80...2000 MHz IEC 61000-4-3 || electrical fast transient/burst immunity test, 1 kV I/O IEC 61000-4-4 || electrical fast transient/burst immunity test, 1 kV shielded cable IEC 61000-4-4 || electrical fast transient/burst immunity test, 2 kV power lines IEC 61000-4-4 || 1.2/50 µs shock waves immunity test, 0.5 kV differential mode IEC 61000-4-5 || 1.2/50 µs shock waves immunity test, 1 kV common mode IEC 61000-4-5 || conducted RF disturbances IEC 61000-4-6 || conducted and radiated emissions CISPR 11
    • Ambient Air Temperature For Operation : -10-55 °C without derating horizontal installation) || -10-60 °C with derating factor horizontal installation) || -10-50 °C vertical installation)
    • Ip Degree Of Protection : IP20IEC 61131-2
    • Vibration Resistance : 1 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz DIN rail
    • Shock Resistance : 15 gn 11 ms
    • Pollution Degree : 2 IEC 60664
    • Ambient Air Temperature For Storage : -40-70 °C
    • Relative Humidity : 5-95 % without condensation
    • Operating Altitude : 0...6561.68 ft (0...2000 m)
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1511026EN
    • Sustainable Offer Status : Green Premium product
    • Pvc Free : Yes
    • Toxic Heavy Metal Free : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Reach Free Of Svhc : Yes
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • China Rohs Regulation : X
    • Circularity Profile : ENVEOLI1511026EN
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
  • Complementary
    • Discrete Input Current : 5-11 mA
    • Discrete Input Voltage Type : AC
    • Marking : CE
    • Electrical Connection : 2 wires
    • Input Voltage Limits : 100...240 V
    • Net Weight : 0.025 kg
    • Current Consumption : 34 mA 5 V DC bus
    • Maximum Power Dissipation In W : 1.08 W
    • Color : Black
    • Isolation : no insulation between channels || 2500 V AC insulation between channel and bus for 1 minute
    • Local Signalling : 1 LED green power supply || 1 LED red power supply || 4 LEDs green input status
    • Range Compatibility : Modicon M258 || Modicon LMC058 || PacDrive LMC motion controller
    • Product Compatibility : PacDrive LMC Pro || logic controller || PacDrive LMC Pro 2 || motion controller || PacDrive LMC Eco
    • Input Filtering : <= 25 ms configurable by software || <= 30 ms hardware from state 1 to state 0 || <= 40 ms hardware from state 0 to state 1
  • Specifications
    • Range Of Product : Modicon TM5
    • Discrete Input Voltage : 100...240 V
    • Product Or Component Type : discrete input module
    • Discrete Input Number : 4
