NEMA Motor Starter, Type S, replacement coil, Series B, 440/480VAC 50/60Hz, NEMA size 5 starter and 8903SX lighting

SQD 3109632055 SIZE 5 440/480

SQD3109632055 3109632055 785901376804
861.65 / EACH
http://schema.org/OutOfStock
Mayer-DDS-NEMA Motor Starter, Type S, replacement coil, Series B, 440/480VAC 50/60Hz, NEMA size 5 starter and 8903SX lighting-2
  • Warranty Length: 18 mth
The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SG Series B contactor, an 8536SG Series B starter or an 8903SX Series B lighting contactor. This coil is rated for 440/480 VAC 50/60 Hz. The inrush power of this coil is 1300 VA. It has an average sealed consumption of 14 VA. Coil has screw clamp connections.
QTY
  • Product Description
  • Specifications
The coil can be easily replaced in a Type S contactor or starter. By changing out the coil, the contactor or starter can be used in different control circuit voltage applications. This will also save the cost of a whole new contactor or starter if the coil were to fail. This coil is used in an 8502SG Series B contactor, an 8536SG Series B starter or an 8903SX Series B lighting contactor. This coil is rated for 440/480 VAC 50/60 Hz. The inrush power of this coil is 1300 VA. It has an average sealed consumption of 14 VA. Coil has screw clamp connections.
  • Complementary Attributes
    • UE Rated Operational Voltage : 440/480 V AC 60 Hz
  • Important Information Attributes
    • Persona Type Ids : EU, LC, OM, OM8, PB
    • Persona Type Names : End User, Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
    • Market Segmentation Id : COMMERCIAL, INDUSTRIAL
    • Market Segmentation : Commercial, Industrial
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-18
    • HTML Description : Replacement AC Magnetic CoilSize 5440/480V AC 60 Hz
    • Manufacturer : Schneider Electric
    • Serviceability : No
    • Traceability : No
    • Field Service Division : PPIBS
    • Legacy WEEE Scope : Out
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • ROHS EUR In Scope : No
    • ROHS EUR Full Compliance Status : Not applicable, out of EU RoHS legal scope
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 1 - GSC certified
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Energy Efficiency Optimized : False
    • Package Weight Lbs : 1.474 kg
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : coil
    • Returnability : Yes
    • Sustainable Packaging : No
    • Relationship Type : Compatible relationship
    • Product Kit Identifier : N
    • Product Manager : STEVEN NATALE
  • Environment Attributes Main
    • EU ROHS Directive : Not Applicable/Out of Scope​, Not applicable, out of EU RoHS legal scope
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • Nema Size : 5
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Product Compatibility : motor starter class 8502 type SG
  • General Attributes
    • Product Or Component Type : coil
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
