Motor starter, TeSys N, nonreversing, Size 4, 135A, 3 pole, 100 HP at 575V, pre-assembled with Motor Logic SSOLR, 120VAC 60Hz coil

STARTER NEMA SZ4 3P 120VAC

SQDT36FN13G7 T36FN13G7 785901084969
2776.92 / EA
http://schema.org/OutOfStock
Mayer-DDS-Motor starter, TeSys N, nonreversing, Size 4, 135A, 3 pole, 100 HP at 575V, pre-assembled with Motor Logic SSOLR, 120VAC 60Hz coil-1
  • Country of Origin: USA
TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. The NEMA size is printed directly on the face of the contactor. This is a 3 pole, 100A, non reversing, NEMA Size 4 starter rated 100 HP at 575Vac. A Motor Logic overload relay is used on this starter. To maximize convenience and to reduce inventory the TeSys N starter uses the common TeSys accessories. The starter has a 120 VAC replaceable coil. Starter is UL listed and CSA Certified.
QTY
  • Product Description
  • Features
  • Specifications
TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. The NEMA size is printed directly on the face of the contactor. This is a 3 pole, 100A, non reversing, NEMA Size 4 starter rated 100 HP at 575Vac. A Motor Logic overload relay is used on this starter. To maximize convenience and to reduce inventory the TeSys N starter uses the common TeSys accessories. The starter has a 120 VAC replaceable coil. Starter is UL listed and CSA Certified.
  • Rated Power In HP
    • 40 HP 200 V AC
    • 50 HP 230 V AC
    • 100 HP 460 V AC
    • 100 HP 575 V AC
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • UC Control Circuit Voltage
    • 120 V AC
  • Market Segmentation
    • Commercial
    • Industrial
  • Persona Type Names
    • End User
    • Contractor
    • Original Equipment Manufacturer
    • OEM - Control Panelbuilder
    • Panel Builder
    • Electrician
  • Persona Type Ids
    • EU
    • LC
    • OM
    • OM8
    • PB
    • SC
  • Thermal Overload Type
    • solid state Motor Logic class 10/20 45-135 A
  • Market Segmentation Id
    • COMMERCIAL
    • INDUSTRIAL
  • UE Rated Operational Voltage
    • 600 V AC
  • Important Information Attributes
    • B2B Bullet Point 1 : Flexible with four overload relays types
    • B2B Bullet Point 2 : Customizable with hundreds of combinations
    • B2B Bullet Point 3 : Streamline installation, wiring, maintenance and field modifications
    • B2B Bullet Point 4 : Reliable build for long mechanical life and electrical endurance
    • B2B Bullet Point 5 : Ideal for use in construction, industrial markets, building automation
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-13
    • Legacy WEEE Scope : In
    • WEEE Product Category : 5
    • Scope Perimeter : Outside of Europe
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Conformity Date : 2011
    • ROHS EUR Full Compliance Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • WD Status : 1 - GSC certified
    • Tier Id : 2
    • Tier : 2
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Electrical Connection : lugs
    • Energy Efficiency Optimized : False
    • Motor Starter Type : non reversing
    • Package Weight Lbs : 6.709 kg
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : starter
    • Range Of Product : TeSys N
    • Returnability : No
    • Sustainable Packaging : No
    • Nbr Of Units In Pkg : 1
    • Warranty In Months : 18
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=469004272&lang=en-us
    • Take Back : No
    • Reach Free SHVC : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • EU ROHS Directive : Compliant with Exemptions
    • Nema Size : 4
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Free Of SVHC : Yes
  • General Attributes
    • Product Or Component Type : starter
    • Range Of Product : TeSys N
  • Specifications
    • Country of Origin : United States
