SQUARE D

Contactor, Type S, multipole lighting, mechanically held, 400A, 3 pole, 110/120VAC 50/60Hz coil, open style

3P 400A 120V LT

SQD8903SYO17V02 8903SYO17V02 785901716952
22061.53 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Contactor, Type S, multipole lighting, mechanically held, 400A, 3 pole, 110/120VAC 50/60Hz coil, open style-1
  • Certifications: CSA, UL Listed
  • Contact Configuration: Without
  • Depth: 267 mm
  • Height: 533 mm
  • Line Rated Current: 400 A
  • Warranty Length: 18 mth
  • Width: 220 mm
QTY
  • Specifications
  • Environment
    • Product Certifications : UL Listed || CSA
    • Nema Degree Of Protection : not rated (open device) surface none
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Eu Rohs Directive : Not compliant
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Complementary
    • Local Signalling : without pilot light
    • Height : 533 mm
    • Auxiliary Contact Composition : without
    • Control Type : no control units
    • [Uc] Control Circuit Voltage : 120 V AC 60 Hz || 110 V AC 50 Hz
    • Poles Description : 3P
    • Electrical Connection : lugs
    • Line Rated Current : 400 A
    • Width : 220 mm
    • Depth : 267 mm
    • Additional Included Device : none
  • Specifications
    • Range Of Product : S
    • Product Or Component Type : Mechanically Held Lighting Contactor
