Contactor, Type L, hoisting, mechanically held, latch attachment, 24VAC 60 Hz coil

HOIST CONTACTOR 600VAC 40A DPR

SQD8965DPR44V02 8965DPR44V02 785901168959
2856.17 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Contactor, Type L, hoisting, mechanically held, latch attachment, 24VAC 60 Hz coil-1
  • Warranty Length: 18 mth
8965 reversing hoist contactors are designed for control of hoists, overhead doors, small elevators and commercial laundry equipment. They are rated to perform in the short periods of jogging experienced in hoist service. This 3 pole contactor is for 600VAC three phase applications. This 3 pole contactor has ratings of 7.5HP at 230VAC single phase and 20HP at 575VAC three phase. The replaceable coil is available with a variety of coil voltages. This device has a 24VAC 60 Hz coil. This reversing contactor doesn't have an enclosure. 8965DPR reversing hoist contactors are UL component recognized and CSA certified.
QTY
  • Product Description
  • Specifications
8965 reversing hoist contactors are designed for control of hoists, overhead doors, small elevators and commercial laundry equipment. They are rated to perform in the short periods of jogging experienced in hoist service. This 3 pole contactor is for 600VAC three phase applications. This 3 pole contactor has ratings of 7.5HP at 230VAC single phase and 20HP at 575VAC three phase. The replaceable coil is available with a variety of coil voltages. This device has a 24VAC 60 Hz coil. This reversing contactor doesn't have an enclosure. 8965DPR reversing hoist contactors are UL component recognized and CSA certified.
  • Complementary Attributes
    • Maximum Horse Power Rating : 10-10 hp 230 V AC, 3 phase, 3-3 hp 115 V AC, 1 phase, 7.5-7.5 hp 230 V AC, 1 phase, 20-20 hp 460 V AC, 3 phase, 20-20 hp 575 V AC, 3 phase
    • UC Control Circuit Voltage : 110 V AC 50 Hz, 120 V AC 60 Hz
    • UE Rated Operational Voltage : 600 V AC
  • Important Information Attributes
    • Persona Type Ids : LC, OM, OM8, PB
    • Persona Type Names : Contractor, Original Equipment Manufacturer, OEM - Control Panelbuilder, Panel Builder
    • Market Segmentation Id : COMMERCIAL, INDUSTRIAL
    • Market Segmentation : Commercial, Industrial
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-13
    • Device Type : LV equipment - LV contactor
    • Serviceability : No
    • Traceability : No
    • Field Service Division : PPIBS
    • Average Life Duration : 20 year(s)
    • Legacy WEEE Scope : In
    • Scope Perimeter : Outside of Europe
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Energy Efficiency Optimized : False
    • Package Weight Lbs : 1.814 kg
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : Reversing Hoist Contactor
    • Range Of Product : DPR
    • Returnability : No
    • Sustainable Packaging : Yes
    • Product Kit Identifier : N
    • Product Manager : STEVEN NATALE
  • Environment Attributes Main
    • EU ROHS Directive : Compliant By Exemption​, Compliant with Exemptions
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • General Attributes
    • Product Or Component Type : Reversing Hoist Contactor
    • Range Of Product : DPR
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
