This Harmony XB4 plain lens push to test modular yellow pilot light is supplied with 110V to 120V AC, uses a universal LED. It has a metal bezel. Under normal conditions, the push-to-test pilot light is providing a best-in-class illumination to service your panel signalisation functions. During maintenance, one push on the head is enough to test the lamp and to confirm its good health. It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66 / IP67 / IP69 / IP69K, making it ideal for operation in harsh environments.

• Physical Attributes
• Embedding Depth : 43 mm
• Conformance Attributes
• Standards : CSA C22.2 No 14, IEC 60947-1, IEC 60947-5-1, IEC 60947-5-4, GB 14048.5, JIS C8201-5-1, UL 508, JIS C8201-1
• Complementary Attributes
• UI Rated Insulation Voltage : 600 V 3)IEC 60947-1, 600 V 3)IEC 60947-1, 600 V 3)IEC 60947-1
• UIMP Rated Impulse Withstand Voltage : 6 kV IEC 60947-1, 6 kV IEC 60947-1
• US Rated Supply Voltage : 110...120 V AC 50/60 Hz, 110...120 V AC 50/60 Hz, 110...120 V AC 50/60 Hz
• Important Information Attributes
• Overvoltage Category : class II conforming to IEC 60536, class II conforming to IEC 60536
• Resistance To High Pressure Washer : 7000000 Pa 55 °C 0.1 m, 7000000 Pa 55 °C 0.1 m, 7000000 Pa 55 °C 0.1 m
• Shock Resistance : 30 gn 18 ms) half sine wave acceleration IEC 60068-2-6, 30 gn 18 ms) half sine wave acceleration IEC 60068-2-6, 30 gn 18 ms) half sine wave acceleration IEC 60068-2-6, 30 gn 18 ms) half sine wave acceleration IEC 60068-2-6, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6, 50 gn 11 ms) half sine wave acceleration IEC 60068-2-6
• Tightening Torque : 0.8-1.2 N.m IEC 60947-1, 0.8-1.2 N.m IEC 60947-1
• Vibration Resistance : 5 gn (f= 12-500 Hz) conforming to IEC 60068-2-6, 5 gn (f= 12-500 Hz) conforming to IEC 60068-2-6, 5 gn (f= 12-500 Hz) conforming to IEC 60068-2-6
• Connections Terminals : screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27, screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27, screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27, screw clamp terminals, <= 2 x 1.5 mm² with cable end IEC 60068-2-27, screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27, screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27, screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27, screw clamp terminals, 1 x 0.22...2 x 2.5 mm² without cable end IEC 60068-2-27
• Local Data Status : Publishable
• Local Publishable Date : 2025-11-25
• Legacy WEEE Scope : In
• Scope Perimeter : At least in Europe
• EOLI Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1808008EN
• Product Repair Index Dam Doc : XB4BS8442-ENVREPAIR-A-EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• ROHS EUR In Scope : Yes
• ROHS EUR Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status : Compliant with Exemptions
• ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
• China ROHS In Scope : Yes
• With Recycled Cardboard : Yes
• Without Single Use Plastic : Yes
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
• Bezel Material : metal
• Compatibility Code : XB4
• Device Short Name : XB4
• Fixing Collar Material : metal
• Important Message : A change in appearance may be noted on the product but does not affect its use in terms of function and safety. This makes it compatible with our Universal LED blocks
• Mounting Diameter : 22.5 mm
• Package Weight Lbs : 100.0 g
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : push-to-test pilot light
• Product Repair Index : A
• Range Of Product : Harmony XB4
• Returnability : Yes
• Service Life : 1.5 year(s)
• Shape Of Signaling Unit Head : round
• Signalling Type : steady
• Sustainable Packaging : Yes
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Product Repair Index Dam Document Id : XB4BS8442-ENVREPAIR-A-EN
• Pep Code : ENVPEP1808008EN
• Product Kit Identifier : N
• Environment Attributes Main
• EU ROHS Directive : Compliant By Exemption​, Compliant with Exemptions
• IP Degree Of Protection : IP66 IEC 60536, IP66 IEC 60536, IP67, IP69, IP69K
• Nema Degree Of Protection : NEMA 13 IEC 60529, NEMA 13 IEC 60529, NEMA 4X
• ROHS Exemption Information : Yes
• Take Back : No
• Recycled Metal Content At Cr Level : 0 %
• China ROHS Regulation : X
• Mercury Free : Yes
• Circularity Profile : ENVEOLI1808008EN
• Environmental Disclosure : ENVPEP1808008EN
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : Yes
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Pep Code : ENVPEP1808008EN
• General Attributes
• Product Or Component Type : push-to-test pilot light
• Range Of Product : Harmony XB4
• Surge Protection And Filtering Attributes
• Surge Withstand : 1 kV
