This Harmony ZB6ZB45B is a red light block with body/fixing collar with integral LED 12V to 24V, 1 NO + 1 NC. It is part of the range Harmony XB6 diameter 16mm monolithic plastic push buttons, switches, and pilot lights.

• Connections Terminals
• Faston connector 2.8 x 0.5 mm
• Uimp Rated Impulse Withstand Voltage
• 4 kV IEC 60947-1
• Supply Voltage Limits
• 6-30 V AC/DC
• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Carbon Footprint Of The Installation Phase A5
• 0.001240137
• 0 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4
• 0 kg CO2 eq.
• 0.0199575342
• Standards
• CSA C22.2 No 14
• JIS C 852
• IEC 60947-1
• UL 508
• IEC 60947-5-5
• IEC 60947-5-1
• JIS C 4520
• Ui Rated Insulation Voltage
• 250 V 3)IEC 60947-1
• Carbon Footprint Of The Manufacturing Phase A1 To A3
• 0.2 kg CO2 eq.
• 0.2457328767
• Electrical Shock Protection Class
• class II conforming to IEC 61140
• Electrical Durability
• 1000000 cycles, AC-15, 2 A 230 V 3600 cyc/h 0.5 IEC 60947-5-1 appendix C
• 1000000 cycles, AC-15, 2 A 230 V 36
• Operating Force
• 1.6 N NO changing electrical state
• 2.5 N NC changing electrical state
• Vibration Resistance
• +/- 3 mm (f= 2-500 Hz) conforming to IEC 60068-2-6
• 5 gn (f= 2-500 Hz) conforming to IEC 60068-2-6
• 5 gn (f
• Positive Opening
• with IEC 60947-5-1 appendix K
• Carbon Footprint Of The Use Phase B2 B3 B4 B6
• 0.4 kg CO2 eq.
• 0.3965891348
• Resistance To Fast Transients
• 2 kV IEC 61000-4-4
• Surge Withstand
• 1 kV direct contact IEC 61000-4-5
• 2 kV in free air IEC 61000-4-5
• Us Rated Supply Voltage
• 12...24 V AC/DC
• Electromagnetic Emission
• class B IEC 55011
• Resistance To Electrostatic Discharge
• 6 kV on contact (on metal parts) IEC 61000-2-6
• 8 kV in free air (in insulating parts) IEC 61000-2-6
• 8 kV in
• Carbon Footprint Of The Distribution Phase A4
• 0.0014384247
• 0 kg CO2 eq.
• Short Circuit Protection
• 6 A cartridge fuse gG IEC 60947-5-1
• Ie Rated Operational Current
• 3 A 120 V, AC-15, B300
• 1.5 A 240 V, AC-15, B300
• 0.1 A 250 V, DC-13, R300
• 0.1 A 250 V,
• Resistance To Electromagnetic Fields
• 10 V/m IEC 61000-4-3
• Operating Travel
• 1 mm NC changing electrical state)
• 2 mm NO changing electrical state)
• 4.3 mm total travel)
• Electrical Reliability
• λ = 10exp(-8) 5 V 1 mA with confidence level of 90 % IEC 60947-5-4
• λ = 10exp(-8) 5 V 1 mA with confidence level of 90 %
• Shock Resistance
• 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27
• 50 gn 11 ms) half sine wave ac
• Product Certifications
• GOST
• CCC
• UL
• CSA

• Physical Attributes
• Cad Overall Depth : 51 mm
• Cad Overall Height : 18 mm
• Cad Overall Width : 24 mm
• Light Source Color : red
• Important Information Attributes
• Country Id : US
• Local Data Status : Publishable
• Local Publishable Date : 2025-07-09
• ETIM 10 : EC000204
• Manufacturing Carbon Footprint : 0.2457328767
• Distribution Carbon Footprint : 0.0014384247
• Installation Carbon Footprint : 0.001240137
• Use Carbon Footprint : 0.3965891348
• End Of Life Carbon Footprint : 0.0199575342
• Legacy WEEE Scope : In
• WEEE Product Category : 5
• Scope Perimeter : At least in Europe
• EOLI Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI2403025EN
• ROHS Eur In Scope : No
• ROHS Eur Status : Compliant with Exemptions
• ROHS Eur Conformity Date : 1930
• ROHS Eur Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
• ROHS Eur Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
• China ROHS In Scope : Yes
• China ROHS Label : 5
• With Recycled Cardboard : Yes
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : N
• WD Status : 1 - GSC certified
• Bulb Base : integral LED
• Compatibility Code : ZB6
• Contact Operation : slow-break
• Contacts Material : silver alloy (Ag/Ni)
• Contacts Type And Composition : 1 NO + 1 NC
• Contacts Usage : standard
• Current Consumption : 15 mA
• Device Short Name : ZB6
• Fixing Collar Material : plastic
• Light Source : LED
• Light Source Color : red
• Package Weight Lbs : 11.000 g
• Product Availability : Non-Stock - Not normally stocked in distribution facility
• Product Or Component Type : complete body for illuminated push-button
• Protective Treatment : TC
• Range Of Product : Harmony XB6
• Returnability : No
• Sale Per Indivisible Quantity : 1
• Signalling Type : steady
• Sustainable Packaging : No
• Terminals Description Iso N 1 : (11-12)NC
• Total Lifecycle Carbon Footprint : 0.7 kg CO2 eq.
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 0.6649581074
• General Attributes
• Product Or Component Type : complete body for illuminated push-button
• Range Of Product : Harmony XB6
• Environment Attributes
• ROHS Exemption Information : Yes
• China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=652066&lang=en-us
• Take Back : No
• Recycled Metal Content At Cr Level : 0 %
• China ROHS Regulation : X
• Mercury Free : Yes
• Carbon Footprint : 0.6649581074
• Ambient Air Temperature For Operation : -25-70 °C
• Ambient Air Temperature For Storage : -40-70 °C
• Circularity Profile : ENVEOLI2403025EN
• Environmental Disclosure : ENVPEP2403025EN
• Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : No
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
