SQUARE D

Mini circuit breaker, QO, 50A, 3 pole, 208Y/120VAC, 10kA, plug in, 6mA grd fault A, pigtail [TAA]

MINIATURE CIRCUIT BREAKER 208Y

SQDQO350GFI QO350GFI 785901218999
821.08 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QO, 50A, 3 pole, 208Y/120VAC, 10kA, plug in, 6mA grd fault A, pigtail [TAA]-2
  • Country of Origin: Mexico
  • Depth: 2.91 in
  • Height: 4.13 in
  • Warranty Length: 18 mth
  • Width: 2.24 in
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positiv
QTY
  • Product Description
  • Features
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positiv
  • Circuit Breaker Type
    • ground fault protecting class A 6 mA
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Ue Rated Operational Voltage
    • 208Y/120 V AC
  • Accessories
    • HLO1
    • QO3HT
    • GFI2PA
    • QO1HPL
    • QO1PL
    • QO2DTI
  • Persona Type Names
    • End User
    • Contractor
    • Original Equipment Manufacturer
  • Persona Type Ids
    • EU
    • LC
    • OM
  • Tightening Torque
    • 5-5 N.m
    • 4.6-4.6 N.m 4-20 mm² (AWG 12...AWG 4)
  • AWG Gauge
    • AWG 12...AWG 4 aluminium
    • AWG 14...AWG 6 copper
  • Product Certifications
    • UL Listed
    • CSA
  • Complementary Attributes
    • Line Rated Current : 50 A
  • Important Information Attributes
    • Country Id : US
    • B2B Bullet Point 1 : Provides superior circuit protection
    • B2B Bullet Point 2 : Reliable and durable
    • B2B Bullet Point 3 : Plug-on neutral design and shorter footprint for faster installs
    • B2B Bullet Point 4 : Simple design and clear instructions for quick setup
    • B2B Bullet Point 5 : Time-saving diagnostics with touch of a button
    • B2B Bullet Point 6 : This product is TAA compliant.
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-07-09
    • Device Type : LV equipment - Low voltage circuit breaker
    • Serviceability : No
    • Traceability : No
    • Field Service Division : PPIBS
    • Average Life Duration : 15 year(s)
    • Legacy WEEE Scope : In
    • WEEE Product Category : 5
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI2212005
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS Eur In Scope : Yes
    • ROHS Eur Status : Compliant with Exemptions
    • ROHS Eur Conformity Date : 2532
    • ROHS Eur Full Compliance Status : Compliant with Exemptions
    • ROHS Eur Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • With Recycled Cardboard : No
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : A - SELECTED - PCE ONLY (Migration)
    • Tier Id : 1
    • Tier : 1
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : RESIDENTIAL
    • Market Segmentation : Residential
    • H And D Domain : Safety
    • H And D Subrange : RESI
    • H And D Enrichment Assignment : yes
    • H And D Enrichment Function : GFCI
    • H And D Enrichment Class 3 : Earth leakage protection devices
    • H And D Enrichment Class 4 : GFCI
    • Circuit Breaker Application : not rated
    • Electrical Connection : box lugs
    • Energy Efficiency Optimized : False
    • Mounting Mode : plug-in
    • Number Of Spaces Required : 3
    • Package Weight Lbs : 635.029 g
    • Poles Description : 3P
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : miniature circuit-breaker
    • Range Of Product : QO
    • Returnability : Yes
    • Sustainable Packaging : No
    • Relationshiptype : Compatible relationship
  • General Attributes
    • Product Or Component Type : miniature circuit-breaker
    • Range Of Product : QO
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=423253857&lang=en-us
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Ambient Air Temperature For Operation : 40 °C
    • Circularity Profile : ENVEOLI2212005
    • Environmental Disclosure : ENVPEP2212005
    • Eu Rohs Directive : Compliant with Exemptions
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : Mexico
    • Height : 4.13 in
    • Width : 2.24 in
    • Compliance : TAA
    • Depth : 2.91 in
