Mini circuit breaker, QO, 25A, 1 pole, 120/240 VAC, 10 kA, plug in mount

Mini circuit breaker, QO, 25A, 1 pole, 120/240 VAC, 10 kA, plug in mount

SQDQO125 QO125 785901010418
11.92 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3 in
  • Line Rated Current: 25 A
  • Mounting Type: Plug-In
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 0.75 in
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QO miniature breaker is rated as 25 A, 120/240 V, and 1 pole. This unit provides 10 kA breaking capacity and plug in mounting. A full line of factory installed accessories, such as shunt trips, auxiliary switches and alarm switches, is also available QO breakers use a compact 3/4 inch width design for small system footprint. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
  • Product Description
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QO miniature breaker is rated as 25 A, 120/240 V, and 1 pole. This unit provides 10 kA breaking capacity and plug in mounting. A full line of factory installed accessories, such as shunt trips, auxiliary switches and alarm switches, is also available QO breakers use a compact 3/4 inch width design for small system footprint. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
  • Poles Description : 1P
  • Electrical Connection : pressure plate
  • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
  • Mounting Mode : plug-in
  • Maximum Depth : 2.91 in
  • Maximum Height : 3 in
  • Short-Circuit Current : 10 kA || 5 kA
  • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
  • Line Rated Current : 25 A
  • Ambient Air Temperature For Operation : 40 °C
  • Circuit Breaker Application : HACR rated
  • Number Of Spaces Required : 1
  • Range Of Product : QO
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC || 48 V DC
  • Circuit Breaker Type : standard
  • Product Or Component Type : miniature circuit-breaker
  • Maximum Width : 0.75 in
  • Warranty : 18 months
  • Product Certifications : UL Listed || CSA
  • Awg Gauge : AWG 14...AWG 8 copper or aluminium
