Scotch® Tape 69 is a premium grade, edge tear resistant, electrical tape. This printable tape has a non corrosive adhesive and offers solvent resistant protection. It is used as a coil cover, an anchor, a banding, a core, a layer and a crossover insulator. The flame retardant tape is suitable for 600V rated, dry location application motors and transformers.
- Features
- Thermosetting, silicon adhesive provides an increased bond at high temperatures
- Glass cloth backing optimally resists resist shrinking and burning
- Used as a coil cover, anchor, banding, core, layer and crossover insulation
- Printable and provides high mechanical strength and excellent performance by withstanding high temperatures
- Withstands a temperature range of 32 to 392 °F (0 to 200 °C)
- UL Listed, Mil-I-19166C, CSA Certified and RoHS 2011/65/EU Compliant
- Specifications
- Adhesion to Steel : en-CA: 4.4 N/10 mm - en-US: 4.4 N/10 mm - fr-CA: 4.4 N/10 mm
- Adhesive Material : Silicone
- Adhesive Type : Silicone
- Backing Material : Glass cloth
- Backing Thickness (Metric) : 0.125 mm
- Breaking Strength (Imperial) : 314 N/10mm
- Color Family : White
- Dielectric Breakdown : 3000V
- Dielectric Strength : 3000 V
- Electrolytic Corrosion Factor : 0.9
- Elongation at Break : 5 %
- Insulation Resistance : 4.8 x 10^4 megohms
- Maximum Operating Temperature (Celsius) : 200 Degree Celsius
- Maximum Operating Temperature (Fahrenheit) : 392 Degree Fahrenheit
- Overall Length (Imperial) : 66 ft
- Overall Length (Metric) : 20.1 m
- Overall Thickness (Imperial) : 7 mil
- Overall Thickness (Metric) : 0.177 mm
- Overall Width (Imperial) : 0.75 in
- Overall Width (Metric) : 19.05 mm
- Product Color : White
- Product Markets : Electrical Equipment Manufacturing
- Product Type : Glass Cloth Tape
- Shelf Life : 5 Year
- Total Tape Thickness without Liner (Imperial) : 7 mil
- Total Tape Thickness without Liner (Metric) : 0.178 mm
- Total Thickness : 0.177 mm
- UL 510 : Yes
