Certifications:
UL E-6294
-
Depth:
5.07 in
-
Height:
35.13 in
-
Line Rated Current:
150 A
-
Mounting Type:
Surface
-
Number of Circuits:
16
-
Number of Phases:
1
-
Short Circuit Current:
22 kA
-
Warranty Length:
18 mth
-
Width:
14.37 in
The Square D® Load Centers and Combination Service Entrance Devices, RC816F150C. Enclosure mounting style performed as surface mount or convertible to semi-flush (use appropriate flange kit). This HOM Ringless Meter Mains meets Federal Specification W-P-115c as Type 1, Class 2, are UL Listed, suitable only for use as service equipment. In interior single main service disconnect with feed-thru lugs. Meter Socket has no By-pass.
