All in one, Homeline, combination service entrance, ringless socket, 200A, surface, 20 spaces, 40 circuits, 22kA SCCR, OH, UG, no bypass

ALL IN ONE RINGLESS OH UG 200A

SQDRC2040M200C RC2040M200C 785901193364
1505.98 / EACH
http://schema.org/OutOfStock
All in one, Homeline, combination service entrance, ringless socket, 200A, surface, 20 spaces, 40 circuits, 22kA SCCR, OH, UG, no bypass
  • Depth: 5.07 in
  • Height: 36.69 in
  • Line Rated Current: 200 A
  • Mounting Type: Surface
  • Number of Circuits: 40
  • Short Circuit Current: 22 kA
  • Warranty Length: 18 mth
  • Width: 14.37 in
The Square D® Load Centers and Combination Service Entrance Devices, RC2040M200C, meets Federal Specification W-P-115c as Type 1, Class 2, are UL Listed, suitable only for use as service equipment, meets EUSERC standards .
QTY
  • Product Description
  • Specifications
The Square D® Load Centers and Combination Service Entrance Devices, RC2040M200C, meets Federal Specification W-P-115c as Type 1, Class 2, are UL Listed, suitable only for use as service equipment, meets EUSERC standards .
  • Complementary
    • Height : 36.69 in
    • Tightening Torque : main lugs 250 lb.in, AWG 6...350 kcmil, aluminium/copper || service ground 50 lb.in, AWG 14...AWG 2/0, copper || service ground 50 lb.in, AWG 12...AWG 2/0, aluminium || branch lugs 50 lb.in, AWG 14...AWG 1/0, copper || branch lugs 50 lb.in, AWG 12...AWG 1/0, aluminium || branch lugs 35 lb.in, AWG 6...AWG 4, aluminium/copper || branch lugs 25 lb.in, AWG 8, aluminium/copper || branch lugs 20 lb.in, AWG 14...AWG 10, aluminium/copper || branch lugs 20 lb.in, AWG 12...AWG 10, aluminium/copper || Cover 10 lb.in
    • Branch Circuit Breaker Rated Current : 200 A
    • Bypass Type : no bypass
    • Service Feed Location : OH || UG
    • Bus Rated Current : 200.0 A
    • Electrical Connection : lugs, line side || lugs, service ground
    • Number Of Circuits : 40
    • Number Of Spaces : 20
    • Short-Circuit Current : 22 kA
    • Number Of Tandem Circuit Breakers : 20
    • Service Disconnect Rated Current : 200 A
    • Line Rated Current : 200 A
    • Width : 14.37 in
    • Awg Gauge : AWG 6...350 kcmil (aluminium) line side || AWG 6...350 kcmil (copper) line side || AWG 12...AWG 2/0 (aluminium) service ground || AWG 12...AWG 2/0 (copper) service ground
    • Depth : 5.07 in
    • Device Composition : service disconnect (factory installed)
    • Device Mounting : surface
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1407020EN
    • Sustainable Offer Status : Green Premium product
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Circularity Profile : N/A
    • Eu Rohs Directive : Compliant with Exemptions
  • Contractual warranty
    • Warranty : 18 months
  • Specifications
    • Range Of Product : Homeline
    • Product Or Component Type : All-In-One
    • Hub Type : A
    • Meter Socket Type : ringless
