Base station, Harmony eXLhoist, compact, Receiver, 10 relays outputs, pre wired 1.5 m cable, 48...240V AC

HARMONY EXLHOIST, COMPACT, REC

SQDZARB10WSP 3606481389121
551.41 / EA
http://schema.org/OutOfStock
Mayer-DDS-Base station, Harmony eXLhoist, compact, Receiver, 10 relays outputs, pre wired 1.5 m cable, 48...240V AC-2
  • Certifications: CE
  • Depth: 51 mm
  • Height: 117 mm
  • Material: ABS
  • Net Weight: 0.88 kg
  • Storage Temperature: -40-70 °C
  • Width: 120 mm
This Harmony eXLhoist / XAR green base station (receiver) has 10 relays outputs with 2 safety relays. This green base station (receiver) is designed as receiver for wireless remote control system. It has 10 relay outputs with 2 safety relays and has wired connection cable gland. It is impact resistant, dust resistant, water resistant, corrosion resistant, and vibration resistant thanks to its IP66, making it ideal for operation in harsh (heavy) environments. It provides complete innovative crane operator control solutions to help improve machine and crane operator efficiency. Base station (receiver) has a unique identification code to allow the consistent and stable connection with its compatible remote control system.
QTY
  • Product Description
  • Specifications
This Harmony eXLhoist / XAR green base station (receiver) has 10 relays outputs with 2 safety relays. This green base station (receiver) is designed as receiver for wireless remote control system. It has 10 relay outputs with 2 safety relays and has wired connection cable gland. It is impact resistant, dust resistant, water resistant, corrosion resistant, and vibration resistant thanks to its IP66, making it ideal for operation in harsh (heavy) environments. It provides complete innovative crane operator control solutions to help improve machine and crane operator efficiency. Base station (receiver) has a unique identification code to allow the consistent and stable connection with its compatible remote control system.
  • Complementary
    • Height : 117 mm
    • Maximum Switching Current : 10 A
    • Fixing Mode : 4 holes
    • Transmission Frequency : 2.4 GHz
    • Relay Type : motion relay outputs 9 NO || auxiliary relay outputs 1 NO
    • Material : ABS + PC
    • Net Weight : 0.88 kg
    • Communication Network Type : wireless Zigbee
    • Nominal Output Current : 0.5 A 48 V AC IEC 60947-5-1
    • [Us] Rated Supply Voltage : 48...240 V AC
    • Maximum Sensing Distance : 100 m in free field
    • Mechanical Durability : 10000000 cycles
    • Maximum Switching Voltage : 240 V AC +/- 20 %)
    • Cable Entry : cable pre-wired
    • Provided Equipment : internal antenna
    • Number Of Relays : 10
    • Width : 120 mm
    • Depth : 51 mm
    • Safety Outputs : 2 NC relay outputs
    • Electrical Durability : 100000 cycles
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • China Rohs Regulation : X
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
  • Environment
    • Product Certifications : CE
    • Ambient Air Temperature For Operation : -20-55 °C
    • Radio Agreement : FCC || IC
    • Ip Degree Of Protection : IP66
    • Relative Humidity : 0-97 %
    • Ambient Air Temperature For Storage : -40-70 °C
  • Specifications
    • Range Of Product : Harmony eXLhoist
    • Product Or Component Type : base station
    • Product Specific Application : hoisting applications || material handling
    • Device Short Name : ZARB
